Eye bolt left-hand thread

제품 라인업 — Fasteners · Screws and standard parts

Eye bolt left-hand thread
No. a b c k ø d1 ø d2 kg
30888-0800-02 M8 40 22 9 8.1 18 0.0220
30888-1000-02 M10 50 26 12 10.1 20 0.0380
30888-1000-04 M10 50 40 12 10.1 20 0.0380
30888-1200-02 M12 50 30 14 12.1 25 0.0600
30888-1200-04 M12 50 35 14 12.1 25 0.0600
30888-1600-04 M16 60 40 17 16.1 32 0.1270
30888-2000-02 M20 80 46 22 18.1 40 0.2560
30888-2000-04 M20 80 55 22 18.1 40 0.2560

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
