Eye bolt right-hand thread

제품 라인업 — Fasteners · Screws and standard parts

Eye bolt right-hand thread

No.	a	b	c	k	ø d1	ø d2	kg
30888-0800-01	M8	40	22	9	8.1	18	0.0220
Further informations Weight: 0.0220 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-101	M8	100	22	9	8.1	18	0.0490
Further informations Weight: 0.0490 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-50	M8	50	22	9	8.1	18	0.0290
Further informations Weight: 0.0290 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-60	M8	60	22	9	8.1	18	0.0330
Further informations Weight: 0.0330 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-70	M8	70	22	9	8.1	18	0.0370
Further informations Weight: 0.0370 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-80	M8	80	22	9	8.1	18	0.0410
Further informations Weight: 0.0410 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-2000-01	M20	80	46	22	18.1	40	0.2560
Further informations Weight: 0.2560 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
