Eye bolt right-hand thread slotted

제품 라인업 — Fasteners · Screws and standard parts

Eye bolt right-hand thread slotted

No.	a	b	c	k	ø d1	ø d2	kg
30888-0800-050	M8	50	22	9	8.1	18	0.0240
Further informations Weight: 0.0240 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-060	M8	60	22	9	8.1	18	0.0290
Further informations Weight: 0.0290 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-070	M8	70	22	9	8.1	18	0.0330
Further informations Weight: 0.0330 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-080	M8	80	22	9	8.1	18	0.0360
Further informations Weight: 0.0360 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-100	M8	100	22	9	8.1	18	0.0450
Further informations Weight: 0.0450 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
