Eye bolt right-hand thread without shaft

제품 라인업 — Fasteners · Screws and standard parts

Eye bolt right-hand thread without shaft

No.	a	b	c	k	ø d1	ø d2	kg
30888-0600-03	M6	40	30	7	6.1	14	0.0120
Further informations Weight: 0.0120 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-0800-03	M8	40	30	9	8.1	18	0.0220
Further informations Weight: 0.0220 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-1000-03	M10	50	40	12	10.1	20	0.0380
Further informations Weight: 0.0380 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-1200-03	M12	50	35	14	12.1	25	0.0600
Further informations Weight: 0.0600 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30888-1600-03	M16	60	40	17	16.1	32	0.1270
Further informations Weight: 0.1270 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
