Eye nut

제품 라인업 — Fasteners · Screws and standard parts

Eye nut

No.	a	b	c2	ø d1	ø d2	ø d3	ø d4	kg
30838-0600	M6	27	6	27	15	15	6	0.0160
Further informations Weight: 0.0160 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-0800	M8	36	8	36	20	20	8	0.0430
Further informations Weight: 0.0430 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-1000	M10	45	10	45	25	25	10	0.0740
Further informations Weight: 0.0740 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-1200	M12	53	11	54	30	30	12	0.1450
Further informations Weight: 0.1450 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-1600	M16	62	13	63	35	35	14	0.2090
Further informations Weight: 0.2090 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-2000	M20	71	15	72	40	40	16	0.3000
Further informations Weight: 0.3000 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30838-2400	M24	90	20	90	50	50	20	0.5980
Further informations Weight: 0.5980 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
