Headless screw left-hand

제품 라인업 — Fasteners · Screws and standard parts

Headless screw left-hand
No. a c1 kg
30883-0400-030 M4 30 0.0020
30883-0500-040 M5 40 0.0040
30883-0500-050 M5 50 0.0050
30883-0500-060 M5 60 0.0060
30883-0500-080 M5 80 0.0080
30883-0500-100 M5 100 0.0100
30883-0600-040 M6 40 0.0060
30883-0600-050 M6 50 0.0080
30883-0600-060 M6 60 0.0110
30883-0600-080 M6 80 0.0140
30883-0600-100 M6 100 0.0160
30883-0600-130 M6 130 0.0220
30883-0800-050 M8 50 0.0150
30883-0800-060 M8 60 0.0180
30883-0800-080 M8 80 0.0240
30883-0800-090 M8 90 0.0270
30883-0800-120 M8 120 0.0360
30883-1000-060 M10 60 0.0280
30883-1200-080 M12 80 0.0530
30883-1600-080 M16 80 0.1040
30883-2000-100 M20 100 0.2050

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
