Hexagon head screw without shaft

제품 라인업 — Fasteners · Screws and standard parts

Hexagon head screw without shaft
No. a c1 k1 sw kg
30843-0400 M4 25 2.8 7 0.0030
30843-0500 M5 30 3.5 8 0.0050
30843-0600 M6 30 4 10 0.0080
30843-0800 M8 40 5.3 13 0.0180
30843-0800-016 M8 16 5.3 13 0.0180
30843-0800-020 M8 20 5.3 13 0.0140
30843-0800-025 M8 25 5.3 13 0.0180
30843-1000 M10 50 6.4 17 0.0370
30843-1000-025 M10 25 6.4 17 0.0260
30843-1000-030 M10 30 6.4 17 0.0269
30843-1200 M12 70 7.5 19 0.0680
30843-1200-025 M12 25 7.5 19 0.0340
30843-1600 M16 90 10 24 0.1540
30843-2000 M20 100 12.5 30 0.2830

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
