Hexagon nut left-hand

제품 라인업 — Fasteners · Screws and standard parts

Hexagon nut left-hand
No. a k sw kg
30893-0300 M3 2.4 5.5 0.0004
30893-0400 M4 3.2 7 0.0007
30893-0500 M5 4 8 0.0010
30893-0600 M6 5 10 0.0020
30893-0800 M8 6.5 13 0.0040
30893-1000 M10 8 17 0.0100
30893-1200 M12 10 19 0.0150
30893-1400 M14 11 22 0.0220
30893-1600 M16 13 24 0.0300
30893-2000 M20 16 30 0.0540
30893-2400 M24 19 36 0.0950
30893-3000 M30 24 46 0.0950

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
