Hexagon nut right-hand
No. a k sw kg
30892-0300 M3 2.4 5.5 0.0004
30892-0400 M4 3.2 7 0.0007
30892-0500 M5 4 8 0.0012
30892-0600 M6 5 10 0.0020
30892-0800 M8 6.5 13 0.0040
30892-1000 M10 8 17 0.0100
30892-1200 M12 10 19 0.0150
30892-1400 M14 11 22 0.0220
30892-1600 M16 13 24 0.0300
30892-2000 M20 16 30 0.0540
30892-2400 M24 19 36 0.0950
30892-3000 M30 24 46 0.2060

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
