Lock nut right-hand

제품 라인업 — Fasteners · Screws and standard parts

Lock nut right-hand
No. a k sw kg
30892-0300-02 M3 4 5.5 0.0006
30892-0400-02 M4 5 7 0.0009
30892-0500-02 M5 5 8 0.0011
30892-0600-02 M6 6 10 0.0022
30892-0800-02 M8 8 13 0.0050
30892-1000-02 M10 10 17 0.0100
30892-1200-02 M12 12 19 0.0140
30892-1400-02 M14 14 22 0.0230
30892-1600-02 M16 16 24 0.0310
30892-2000-02 M20 20 30 0.0580
30892-2400-02 M24 24 36 0.1050

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
