Washer DIN 125A / ISO 7089
No. k ø d1 ø d2 kg
30896-0300 0.5 7 M3 0.0001
30896-0400 0.5 9 M4 0.0001
30896-0500 1 10 M5 0.0003
30896-0600 1.6 12 M6 0.0008
30896-0800 1.6 16 M8 0.0014
30896-1000 1.6 20 M10 0.0027
30896-1200 2 24 M12 0.0051
30896-1400 2.5 28 M14 0.0050
30896-1600 2.5 30 M16 0.0099
30896-2000 3 37 M20 0.0156
30896-2400 4 44 M24 0.0281
30896-3000 4 56 M30 0.0491

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
