Washer DIN 9021 / ISO 7093

제품 라인업 — Fasteners · Screws and standard parts

Washer DIN 9021 / ISO 7093

No.	k	ø d1	ø d2	kg
30896-0300-09	0.8	9	M3	0.0010
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0010 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-0400-12	1	12	M4	0.0010
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0010 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-0500-15	1.2	15	M5	0.0015
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0015 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-0600-18	1.6	18	M6	0.0020
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0020 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-0800-24	2	24	M8	0.0060
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0060 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-1000-30	2.5	30	M10	0.0120
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0120 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-1200-37	3	37	M12	0.0210
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0210 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-1600-50	3	50	M16	0.0410
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0410 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request
30896-2000-60	4	60	M20	0.0740
Further informations Standard and Classification: DIN 9021/ISO 7093 Weight: 0.0740 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4-70 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
