Shackle omega-type Stainless steel

제품 라인업 — Fasteners · Shakles, hooks, rings

Shackle omega-type Stainless steel

No.	b1	b2	g	NG	ø d1	ø d2	ø d3	WLL kN	kg
30835-0016-01	18	14	8	4	4	4	9	1.4	0.0090
Further informations Surface: polished Weight: 0.0090 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0024-01	23	17	9	5	5	5	11	2.5	0.0170
Further informations Surface: polished Weight: 0.0170 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0036-01	27	21	11	6	6	6	13	4.3	0.0300
Further informations Surface: polished Weight: 0.0300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0056-01	37	28	15	8	8	8	16	7	0.0630
Further informations Surface: polished Weight: 0.0630 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0086-01	46	35	20	10	10	10	20	13.3	0.1320
Further informations Surface: polished Weight: 0.1320 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0130-01	55	42	23	12	12	12	24	15	0.2500
Further informations Surface: polished Weight: 0.2500 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
