Shackle straight shape Stainless steel

제품 라인업 — Fasteners · Shakles, hooks, rings

Shackle straight shape Stainless steel

No.	b1	g	NG	ø d1	ø d2	ø d3	WLL kN	kg
30835-0032	17	9	5	5	5	10	2.5	0.0100
Further informations Surface: polished Weight: 0.0100 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0039	21	11	6	6	6	12	4.3	0.0200
Further informations Surface: polished Weight: 0.0200 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0050	28	15	8	8	8	16	7	0.0500
Further informations Surface: polished Weight: 0.0500 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0090	35	19	10	10	10	20	11.3	0.1100
Further informations Surface: polished Weight: 0.1100 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0120	42	23	12	11	12	24	15	0.1900
Further informations Surface: polished Weight: 0.1900 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0140	45	25	13	13	13	26	16.3	0.2400
Further informations Surface: polished Weight: 0.2400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0200	55	31	16	15	16	31	25	0.4400
Further informations Surface: polished Weight: 0.4400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30835-0340	66	37	19	18	19	38	37.5	0.7500
Further informations Surface: polished Weight: 0.7500 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
