Threaded chain connection Stainless steel

제품 라인업 — Fasteners · Shakles, hooks, rings

Threaded chain connection Stainless steel

No.	ø	b1	b2	g	ø d	WLL kN	kg
30895-0400	4	32	11	5	4	4.6	0.0120
Further informations Surface: polished Diameter: 4 mm Weight: 0.0120 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30895-0500	5	40	14	6	5	7.5	0.0210
Further informations Surface: polished Diameter: 5 mm Weight: 0.0210 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30895-0600	6	48	15	7	6	10.6	0.0350
Further informations Surface: polished Diameter: 6 mm Weight: 0.0350 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30895-0700	7	56	16	8	7	13.3	0.0570
Further informations Surface: polished Diameter: 7 mm Weight: 0.0570 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30895-0800	8	59	17	9	8	17	0.0800
Further informations Surface: polished Diameter: 8 mm Weight: 0.0800 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30895-1000	10	70	21	11	10	28.3	0.1330
Further informations Surface: polished Diameter: 10 mm Weight: 0.1330 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
