Trigger snap Stainless steel

제품 라인업 — Fasteners · Shakles, hooks, rings

Trigger snap Stainless steel

No.	b1	b3	g	NG	ø d1	ø d2	WLL kN	kg
30815-0044	33	4	5	40x4	4	6	0.25	0.0082
Further informations Surface: polished Weight: 0.0082 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0055	41	6	7	50x5	5	8	0.4	0.0170
Further informations Surface: polished Weight: 0.0170 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0066	49	7	7	60x6	6	9	0.75	0.0270
Further informations Surface: polished Weight: 0.0270 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0077	56	8	9	70x7	7	10	1	0.0450
Further informations Surface: polished Weight: 0.0450 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0088	65	9	10	80x8	8	12	1.5	0.0650
Further informations Surface: polished Weight: 0.0650 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-1010	80	13	13	100x10	10	17	2	0.1300
Further informations Surface: polished Weight: 0.1300 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-1211	102	13	17	120x11	11	18	2.25	0.1960
Further informations Surface: polished Weight: 0.1960 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
