Trigger snap with eye Stainless steel

No.	b2	g	NG	ø d1	ø d3	WLL kN	kg
30815-0044-01	34	5	4x40	4	4	0.25	0.0085
Further informations Surface: polished Weight: 0.0085 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0055-01	40	7	5x50	5	6	0.4	0.0170
Further informations Surface: polished Weight: 0.0170 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0066-01	47	8	6x60	6	7	0.75	0.0270
Further informations Surface: polished Weight: 0.0270 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-0088-01	64	10	8x80	8	12	1.5	0.0450
Further informations Surface: polished Weight: 0.0450 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-1010-01	80	13	10x100	10	13	2	0.0650
Further informations Surface: polished Weight: 0.0650 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30815-1211-01	97	16	11x120	11	15	2.25	0.1300
Further informations Surface: polished Weight: 0.1300 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
