Welded ring oval Stainless steel

제품 라인업 — Fasteners · Shakles, hooks, rings

Welded ring oval Stainless steel

No.	b1	b2	ø d	WLL kN	kg
30825-0050	50	20	5	5	0.0210
Further informations Weight: 0.0210 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30825-0200	80	30	10	20	0.1370
Further informations Weight: 0.1370 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30825-0500	110	53	15	50	0.4650
Further informations Weight: 0.4650 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
