제품 라인업 — Frames · ModularRailing
| No. | a | b1 min | b1 max | c1 | c2 | ø d1 | ø d2 | sw | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30917-1000-00 | M8 | 40 | 70 | 16 | 48 | 16 | 20 | 10 | 30 | 30 | 0.1080 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
