Post fitting flat shape for end-stop countersunk head 90° with internal thread

제품 라인업 — Frames · Post fittings

Post fitting flat shape for end-stop countersunk head 90° with internal thread
No. a ø d1 ø d2 kg
30862-0400-10 M4 13 7.3 0.0040
30862-0500-10 M5 13 7.3 0.0040
30862-0600-10 M6 18 8.5 0.0110
30862-0800-10 M8 18 10.5 0.0200

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
