Post fitting flat shape for end-stop with countersunk head 90° Univiss
No. ø ø d1 ø d2 kg
30862-0300-04 3 10 4.3 0.0020
30862-0400-04 4 10 5.5 0.0030
30862-0500-04 5 13 6.5 0.0030
30862-0600-04 6 18 8.5 0.0050
30862-0800-04 8 22 10.5 0.0090

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
