Post fitting round shape for end-stop radius head with internal thread
No. a ø d1 ø d2 kg
30862-0400-09 M4 13 7.3 0.0060
30862-0500-09 M5 13 7.3 0.0060
30862-0600-09 M6 18 8.5 0.0150
30862-0800-09 M8 22 10.5 0.0230

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
