Post fitting round shape for end-stop with countersunk head 90°

제품 라인업 — Frames · Post fittings

Post fitting round shape for end-stop with countersunk head 90°

No.	ø	ø d1	ø d2	kg
30862-0200-03	2	10	5.5	0.0010
Further informations Diameter: 2 mm Weight: 0.0010 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0300-03	3	13	7.3	0.0030
Further informations Diameter: 3 mm Weight: 0.0030 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0400-03	4	13	7.3	0.0050
Further informations Diameter: 4 mm Weight: 0.0050 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0500-03	5	18	8.5	0.0230
Further informations Diameter: 5 mm Weight: 0.0230 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0600-03	6	22	10.5	0.0330
Further informations Diameter: 6 mm Weight: 0.0330 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0800-03	8	24	13.5	0.0500
Further informations Diameter: 8 mm Weight: 0.0500 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
