Post fitting round shape for end-stop with radius head Univiss

No.	ø	ø d1	ø d2	kg
30862-0300-051	3	10	4.3	0.0020
Further informations Diameter: 3 mm Weight: 0.0020 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0400-051	4	10	5.5	0.0040
Further informations Diameter: 4 mm Weight: 0.0040 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0500-051	5	13	7.3	0.0060
Further informations Diameter: 5 mm Weight: 0.0060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0600-051	6	18	8.5	0.0130
Further informations Diameter: 6 mm Weight: 0.0130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0800-051	8	22	10.5	0.0160
Further informations Diameter: 8 mm Weight: 0.0160 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
