Post fitting round shape for external thread
No. a ø d1 ø d2 kg
30862-0300-01 M3 8 3.3 0.0030
30862-0400-01 M4 10 4.3 0.0030
30862-0500-01 M5 10 5.5 0.0030
30862-0600-01 M6 13 7.3 0.0060
30862-0800-01 M8 18 8.5 0.0140
30862-1000-01 M10 22 10.5 0.0300
30862-1200-01 M12 24 13.5 0.0340
30862-1600-01 M16 32 17 0.0450
30862-2000-01 M20 32 21 0.0580
30862-2400-01 M24 40 25 0.1100
