Post fitting round shape for external thread

제품 라인업 — Frames · Post fittings

Post fitting round shape for external thread

No.	a	b	lx	ø d1	ø d2	ø d3	kg
30862-0600-00-17	M6	25	25	13	7	17.2	0.0200
Further informations Weight: 0.0200 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0800-00-26	M8	25	25	18	9	26.9	0.0400
Further informations Weight: 0.0400 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0800-00-33	M8	25	25	18	9	33.7	0.0390
Further informations Weight: 0.0390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-0800-00-42	M8	25	25	18	9	42.4	0.0390
Further informations Weight: 0.0390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-1000-00-33	M10	25	25	22	10.5	33.7	0.0590
Further informations Weight: 0.0590 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30862-1000-00-42	M10	25	25	22	10.5	42.4	0.0580
Further informations Weight: 0.0580 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
