Post fitting round shape  for external thread
No. a α lx ø d1 ø d2 ø d3 kg
30862-0601-17 M6 4 13 6.5 17.2 0.0030
30862-0801-26 M8 4 18 8.5 26.9 0.0060
30862-1001-33 M10 5 22 10.5 33.7 0.0140
30862-1001-42 M10 5 22 10.5 42.4 0.0140

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
