제품 라인업 — Frames · Tubes and accessories
| No. | b1 | b2 | b3 | b4 | b5 | b6 | b7 | c | c1 | c2 | c3 | k | ø d1 | ø d2 | kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30924-0033-080-1 | 120 | 80 | 15 | 15 | 70 | 25 | 36 | 133 | 72 | 36 | 17 | 8 | 36 | 13 | 0.9730 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
