Loop with stainless steel sleeve swaged without thimble

제품 라인업 — Loops · Loops assembled

Loop with stainless steel sleeve swaged without thimble
No. ø b2 ø d1 ø d4 s kg
20803-0200 2 10 variabel 7 variabel 0.0020
20803-0300 3 13 variabel 9 variabel 0.0040
20803-0400 4 16 variabel 13 variabel 0.0120
20803-0500 5 20 variabel 15 variabel 0.0180
20803-0600 6 27 variabel 13 variabel 0.0200
20803-0800 8 36 variabel 20 variabel 0.0500
20803-1000 10 45 variabel 22 variabel 0.0710
20803-1200 12 54 variabel 27 variabel 0.1100
20803-1600 16 80 variabel 36 variabel 0.2920
20803-2000 20 89 variabel 31 variabel 0.2920

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
