Loop with thimble and alu-sleeve swaged

제품 라인업 — Loops · Loops assembled

Loop with thimble and alu-sleeve swaged
No. ø b1 k ø d2 ø d3 kg
20802-0100 1 7.2 4 8 3.4 0.0020
20802-0150 1.5 9.2 4 8 4 0.0020
20802-0200 2 10 4 8 4 0.0020
20802-0300 3 14 5 10 6 0.0040
20802-0400 4 18 6 11 8 0.0120
20802-0500 5 23 7 13 10 0.0180
20802-0600 6 27 9 16 12 0.0200
20802-0800 8 36 12 20 16 0.0400
20802-1000 10 45 15 26 20 0.0710
20802-1200 12 54 17 27 24 0.1100
20802-1600 16 72 21 36 36 0.2920
20802-2000 20 104 31 45 44 0.2920

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
