Loop with thimble and copper sleeve swaged

제품 라인업 — Loops · Loops assembled

Loop with thimble and copper sleeve swaged

No.	ø	b1	k	ø d2	ø d3	s	kg
20806-0200	2	10	4	8	4	30	0.0020
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 2 mm Weight: 0.0020 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-0300	3	14	5	10	6	45	0.0040
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 3 mm Weight: 0.0040 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-0400	4	18	6	11	8	60	0.0120
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 4 mm Weight: 0.0120 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-0500	5	23	7	13	10	75	0.0180
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 5 mm Weight: 0.0180 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-0600	6	27	9	16	12	90	0.0200
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 6 mm Weight: 0.0200 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-0800	8	36	12	20	16	120	0.0400
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 8 mm Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-1000	10	45	14	26	20	150	0.0710
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 10 mm Weight: 0.0710 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-1200	12	54	16	27	24	180	0.1100
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 12 mm Weight: 0.1100 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
20806-1600	16	72	22	36	32	240	0.2920
Further informations Standard and Classification: in compliance with EN 13411-3 Diameter: 16 mm Weight: 0.2920 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
