Loop with thimble and stainless steel sleeve swaged

제품 라인업 — Loops · Loops assembled

Loop with thimble and stainless steel sleeve swaged
No. ø b2 k ø d2 ø d4 s kg
20804-0200 2 10 4 8 7 30 0.0020
20804-0300 3 13 5 10 9 45 0.0040
20804-0400 4 16 6 11 13 60 0.0120
20804-0500 5 20 7 13 15 75 0.0180
20804-0600 6 27 9 16 13 90 0.0200
20804-0800 8 36 12 20 20 120 0.0400
20804-1000 10 45 15 26 22 150 0.0710
20804-1200 12 54 17 27 27 180 0.1100
20804-1600 16 80 21 36 36 240 0.2920
20804-2000 20 89 31 45 41 320 0.2920

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
