2-part loop clamp with thimble self-assembly

제품 라인업 — Loops · Loops self assembly

2-part loop clamp with thimble self-assembly

No.	ø	a	b	k	ø d1	ø d2	sw	F_Rd kN	F_rk kN	kg
30874-0300	3	M4	27	5	22	10	7	5	6.2	0.0720
Further informations Diameter: 3 mm Weight: 0.0720 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0400	4	M4	27	6	22	11	7	5	6.2	0.0690
Further informations Diameter: 4 mm Weight: 0.0690 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0500	5	M6	42	7	28	13	7	6.2	7.8	0.1720
Further informations Diameter: 5 mm Weight: 0.1720 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0600	6	M6	42	9	28	16	10	6.2	7.8	0.1740
Further informations Diameter: 6 mm Weight: 0.1740 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0800	8	M6	42	12	28	20	10	6.2	7.8	0.1620
Further informations Diameter: 8 mm Weight: 0.1620 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
