2-part loop clamp with thimble self-assembly light

제품 라인업 — Loops · Loops self assembly

2-part loop clamp with thimble self-assembly light

No.	ø	a	b	k	ø d1	ø d2	sw	F_Rd kN	F_rk kN	kg
30874-0200-01	2	M4	10	4	15	7	7	0.2	0.2	0.0140
Further informations Diameter: 2 mm Weight: 0.0140 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0300-01	3	M4	10	5	15	10	7	1.8	2.2	0.0230
Further informations Diameter: 3 mm Weight: 0.0230 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0400-01	4	M4	10	6	20	11	7	1.8	2.2	0.0240
Further informations Diameter: 4 mm Weight: 0.0240 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0500-01	5	M6	20	7	28	13	10	2.7	3.4	0.0800
Further informations Diameter: 5 mm Weight: 0.0800 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0600-01	6	M6	20	9	28	16	10	2.7	3.4	0.0790
Further informations Diameter: 6 mm Weight: 0.0790 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0800-01	8	M6	20	12	28	20	10	2.7	3.4	0.0730
Further informations Diameter: 8 mm Weight: 0.0730 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
