2-part loop clamp without thimble self-assembly

제품 라인업 — Loops · Loops self assembly

2-part loop clamp without thimble self-assembly

No.	ø	a	b	ø d1	F_Rd kN	F_rk kN	kg
30874-0300-10	3	M4	27	22	5	6.2	0.0690
Further informations Diameter: 3 mm Weight: 0.0690 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0400-10	4	M4	27	22	5	6.2	0.0630
Further informations Diameter: 4 mm Weight: 0.0630 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0500-10	5	M6	42	28	6.2	7.8	0.1640
Further informations Diameter: 5 mm Weight: 0.1640 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0600-10	6	M6	42	28	6.2	7.8	0.1640
Further informations Diameter: 6 mm Weight: 0.1640 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0800-10	8	M6	42	28	6.2	7.8	0.1440
Further informations Diameter: 8 mm Weight: 0.1440 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
