2-part loop clamp without thimble self-assembly light

제품 라인업 — Loops · Loops self assembly

2-part loop clamp without thimble self-assembly light

No.	ø	a	b	ø d1	F_Rd kN	F_rk kN	kg
30874-0200-11	2	M4	10	15	0.2	0.2	0.0110
Further informations Diameter: 2 mm Weight: 0.0110 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0300-11	3	M4	10	15	1.8	2.2	0.0180
Further informations Diameter: 3 mm Weight: 0.0180 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0400-11	4	M4	10	20	1.8	2.2	0.0180
Further informations Diameter: 4 mm Weight: 0.0180 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0500-11	5	M6	20	28	2.7	3.4	0.0720
Further informations Diameter: 5 mm Weight: 0.0720 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0600-11	6	M6	20	28	2.7	3.4	0.0690
Further informations Diameter: 6 mm Weight: 0.0690 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request
30874-0800-11	8	M6	20	28	2.7	3.4	0.0550
Further informations Diameter: 8 mm Weight: 0.0550 kg Material group: material group AISI 316/1.4401 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
