Rod joiner for Tension rod

제품 라인업 — Rod system · Rod accessories

Rod joiner for Tension rod

No.	a	b	c	ø d	sw	F_Rd kN	kg
32884-0600-03	M6	24	12	10	10		0.0100
Further informations Weight: 0.0100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-0800-03	M8	30	15	12.5	12	16.7	0.0170
Further informations Weight: 0.0170 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1000-03	M10	38	19	14.2	13	26.3	0.0240
Further informations Weight: 0.0240 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1200-03	M12	48	24	19.8	19	38.3	0.0700
Further informations Weight: 0.0700 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1600-03	M16	60	30	23.5	22	70.4	0.1100
Further informations Weight: 0.1100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-2000-03	M20	72	36	31	30	109	0.2400
Further informations Weight: 0.2400 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-2400-03	M24	90	45	39.5	38	157	0.5150
Further informations Weight: 0.5150 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
