External thread rolled right-hand

제품 라인업 — Rod system · Rods nominal size

External thread rolled right-hand

No.	a	b	c	ø d	F_Rd kN	kg
32884-0600-01	M6	variabel / variable	35	5.27		-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-0800-01	M8	variabel / variable	40	7.12	16.7	-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1000-01	M10	variabel / variable	50	8.95	26.3	-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1200-01	M12	variabel / variable	65	10.75	38.3	-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1600-01	M16	variabel / variable	80	14.65	70.4	-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-2000-01	M20	variabel / variable	100	18.25	109	-
Further informations Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-2400-01	M24	variabel / variable	130	21.92	157	7.7220
Further informations Material group: material group AISI 316L/1.4404 Weight: 7.7220 kg Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
