Tension rod

제품 라인업 — Rod system · Rods nominal size

Tension rod

No.	b	NG	ø d	kg
32884-0527	variabel / variable	6	5.27	0.1755
Further informations Surface: ground surface Weight: 0.1755 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-0712	variabel / variable	8	7.12	0.3204
Further informations Surface: ground surface Weight: 0.3204 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-0895	variabel / variable	10	8.95	0.5097
Further informations Surface: ground surface Weight: 0.5097 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1075	variabel / variable	12	10.75	0.7304
Further informations Surface: ground surface Weight: 0.7304 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1465	variabel / variable	16	14.65	1.3565
Further informations Surface: ground surface Weight: 1.3565 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-1825	variabel / variable	20	18.25	2.1050
Further informations Surface: ground surface Weight: 2.1050 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32884-2192	variabel / variable	24	21.92	3.0368
Further informations Surface: ground surface Weight: 3.0368 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
