제품 라인업 — Tensioning components · Turnbuckles assembled
| No. | ø | a | b1 | b2 | ø d | sw | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|---|
| 30816-1000-01 | 10 | M12 | 502 | 190 | 18 | 8 | 82 | 34 | 0.6930 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30816-1200-01 | 12 | M16 | 632 | 238 | 24 | 12 | 104 | 42 | 1.5280 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
| 30816-1600-01 | 16 | M20 | 758 | 288 | 30 | 15 | 124 | 50 | 2.7530 | |
Further informations
Price basis / tiered pricesPrice on request |
||||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
