Turnbuckle Forte round swaged

제품 라인업 — Tensioning components · Turnbuckles assembled

Turnbuckle Forte round swaged

No.	ø	a	b1	b2	ø d	ø d2	F_Rd kN ETA	-	+	x min	kg
32829-0800	8	M12	414	144	20	16.1	30.6	64	38	400	0.6070
Further informations Diameter: 8 mm Weight: 0.6070 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-1000	10	M16	480	160	25	17.9	47.8	70	36	500	1.0050
Further informations Diameter: 10 mm Weight: 1.0050 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-1200	12	M20	546	176	31	21.4	69	76	32	600	1.7470
Further informations Diameter: 12 mm Weight: 1.7470 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-1400	14	M24	656	212	36	25	93.9	92	40	700	2.8690
Further informations Diameter: 14 mm Weight: 2.8690 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-1600	16	M24	692	212	36	28.1	122.4	92	40	800	3.1690
Further informations Diameter: 16 mm Weight: 3.1690 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-1900	19	M30	842	268	46	34.5	172.8	118	50	950	6.2390
Further informations Diameter: 19 mm Weight: 6.2390 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-2200	22	M30	898	268	46	40.5	230.2	118	50	1100	7.3470
Further informations Diameter: 22 mm Weight: 7.3470 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
32829-2600	26	M36	960	280	55	46	315.5	120	42	1300	10.7550
Further informations Diameter: 26 mm Weight: 10.7550 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
