제품 라인업 — Tensioning components · Turnbuckles assembled
| No. | ø | a | b1 | b2 | ø d | - | + | kg | |
|---|---|---|---|---|---|---|---|---|---|
| 30829-0400-10 | 4 | M4 | 129 | 45 | 7 | 20 | 8 | 0.0230 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0500-10 | 5 | M5 | 154 | 80 | 8 | 22 | 15 | 0.0330 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0500-11 | 5 | M5 | 204 | 80 | 8 | 40 | 25 | 0.0430 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0600-10 | 6 | M6 | 178 | 92 | 10 | 20 | 12 | 0.0590 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0600-11 | 6 | M6 | 228 | 92 | 10 | 52 | 22 | 0.0720 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0800-10 | 8 | M8 | 218 | 112 | 13.5 | 17 | 6 | 0.1330 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
| 30829-0800-11 | 8 | M8 | 258 | 112 | 13.5 | 57 | 26 | 0.1570 | |
Further informations
Price basis / tiered pricesPrice on request |
|||||||||
Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.
