Turnbuckle with hook and eye stainless steel

제품 라인업 — Tensioning components · Turnbuckles

Turnbuckle with hook and eye stainless steel

No.	b1	b2	g	k1	k2	NG	ø d1	ø d2	WLL kN	kg
30840-0080-02	115	47	6	5	4	M5	7	17	0.2	0.0400
Further informations Surface: polished Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0160-02	145	90	8	5	4	M6	10	23	0.4	0.1000
Further informations Surface: polished Weight: 0.1000 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0380-02	235	150	12	9	8	M10	15	35	1	0.2700
Further informations Surface: polished Weight: 0.2700 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0680-02	295	200	13	11	10	M12	19	42	2	0.5600
Further informations Surface: polished Weight: 0.5600 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1000-02	375	250	17	15	13	M16	20	50	3	1.0900
Further informations Surface: polished Weight: 1.0900 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1600-02	425	305	20	18	16	M20	28	64	4	1.7300
Further informations Surface: polished Weight: 1.7300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
