Turnbuckle with two eyes stainless steel

제품 라인업 — Tensioning components · Turnbuckles

Turnbuckle with two eyes stainless steel

No.	b1	b2	k1	NG	ø d1	ø d2	WLL kN	kg
30840-0080	79	47	5	M5	7	17	0.8	0.0400
Further informations Surface: polished Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0160	132	90	5	M6	10	23	1.6	0.1000
Further informations Surface: polished Weight: 0.1000 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0380	225	150	9	M10	15	35	3.8	0.3080
Further informations Surface: polished Weight: 0.3080 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0680	285	200	11	M12	19	42	6.8	0.5600
Further informations Surface: polished Weight: 0.5600 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1000	365	250	15	M16	20	50	10	1.0900
Further informations Surface: polished Weight: 1.0900 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1600	415	305	18	M20	28	64	16	1.7300
Further informations Surface: polished Weight: 1.7300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
