Turnbuckle with two hooks stainless steel

제품 라인업 — Tensioning components · Turnbuckles

Turnbuckle with two hooks stainless steel

No.	b1	b2	g	k2	NG	WLL kN	kg
30840-0080-01	115	47	6	4	M5	0.2	0.0400
Further informations Surface: polished Weight: 0.0400 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0160-01	160	65	8	4	M6	0.4	0.1000
Further informations Surface: polished Weight: 0.1000 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0380-01	245	120	12	8	M10	1	0.2700
Further informations Surface: polished Weight: 0.2700 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-0680-01	312	200	13	10	M12	2	0.5600
Further informations Surface: polished Weight: 0.5600 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1000-01	370	250	17	13	M16	3	1.0900
Further informations Surface: polished Weight: 1.0900 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request
30840-1600-01	435	305	20	16	M20	4	1.7300
Further informations Surface: polished Weight: 1.7300 kg Material group: material group AISI 316/1.4401 Nominal strength (Mat. strength): A4 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
