External thread end right-hand Univiss round swaged

제품 라인업 — Threads · External threads

External thread end right-hand Univiss round swaged
No. ø a b c ø d kg
30950-0300-15 3 M3 38 15 3.4 0.0010
30950-0300-30 3 M3 53 30 3.4 0.0010
30950-0400-30 4 M4 52 30 4.2 0.0020
30950-0400-60 4 M4 82 60 4.2 0.0080
30950-0500-30 5 M5 52 30 5.2 0.0070
30950-0500-60 5 M5 82 60 5.2 0.0120
30950-0600-30 6 M6 58 30 6.4 0.0120
30950-0600-60 6 M6 88 60 6.4 0.0190
30950-0800-30 8 M8 68 30 8.4 0.0220
30950-0800-60 8 M8 98 60 8.4 0.0320

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
