Intermediate thread swaged

제품 라인업 — Threads · External threads

Intermediate thread swaged

No.	ø	a	b	c	kg
30802-0300	3	M8	60	18	0.0170
Further informations Diameter: 3 mm Weight: 0.0170 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30802-0400	4	M10	70	13	0.0300
Further informations Diameter: 4 mm Weight: 0.0300 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30802-0500	5	M10	90	24	0.0350
Further informations Diameter: 5 mm Weight: 0.0350 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30802-0600	6	M12	110	32	0.1020
Further informations Diameter: 6 mm Weight: 0.1020 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30802-0800	8	M16	120	27	0.1130
Further informations Diameter: 8 mm Weight: 0.1130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
