Internal thread end left-hand SA self-assembly

제품 라인업 — Threads · Internal threads

Internal thread end left-hand SA self-assembly

No.	ø	a	b	c	ø d1	ø d2	F_Rd kN ETA	F_Rd kN	kg
30937-0200-015	2	M4	38	15	5	6		1.1	0.0060
Further informations Diameter: 2 mm Weight: 0.0060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30937-0300-035	3	M5	70	35	6	8		2.5	0.0180
Further informations Diameter: 3 mm Weight: 0.0180 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30937-0400-035	4	M6	73	35	7	9		4.4	0.0220
Further informations Diameter: 4 mm Weight: 0.0220 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30937-0500-035	5	M6	81	35	8	9		6.1	0.0250
Further informations Diameter: 5 mm Weight: 0.0250 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30937-0600-050	6	M8	108	50	10	12	11.6	8.7	0.0570
Further informations Diameter: 6 mm Weight: 0.0570 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30937-0800-060	8	M10	140	60	13	15	19.3	17.8	0.1100
Further informations Diameter: 8 mm Weight: 0.1100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
