Internal thread end left-hand swaged for rope Ø 2 - 8 mm

제품 라인업 — Threads · Internal threads

Internal thread end left-hand swaged for rope Ø 2 - 8 mm
No. ø a b c ø d F_Rd kN ETA kg
30861-0200-015 2 M4 38 15 6 0.0080
30861-0300-020 3 M5 55 20 7 0.0130
30861-0300-035 3 M5 70 35 7 0.0190
30861-0400-020 4 M6 57 20 8 5.2 0.0170
30861-0400-035 4 M6 73 35 8 5.2 0.0230
30861-0500-020 5 M6 65 20 8 8.1 0.0160
30861-0500-035 5 M6 81 35 8 8.1 0.0230
30861-0600-025 6 M8 83 25 10 11.6 0.0310
30861-0600-050 6 M8 108 50 10 11.6 0.0400
30861-0800-060 8 M10 140 60 13 20.7 0.1060

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
