Internal thread end right-hand swaged for rope Ø 10 - 16 mm

제품 라인업 — Threads · Internal threads

Internal thread end right-hand swaged for rope Ø 10 - 16 mm

No.	ø	a	b	c	ø d	F_Rd kN ETA	kg
30860-1000-080	10	M12	190	80	18	32.3	0.2640
Further informations Diameter: 10 mm Weight: 0.2640 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30860-1200-100	12	M16	238	100	24	46.5	0.2910
Further informations Diameter: 12 mm Weight: 0.2910 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30860-1600-120	16	M20	288	120	30	82.5	1.0100
Further informations Diameter: 16 mm Weight: 1.0100 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
